TATA GOLD
PVC WIRES & CABLES
"Making difference in electric"
Engineered with 99.99% Electrolytic Pure Copper and advanced Flame Retardant PVC insulation. Designed for maximum electrical conductivity, minimal energy loss, and total fire safety for modern homes and commercial infrastructure.
99.99% Pure
Electrolytic Copper
FR & FRLS
Flame Retardant
ISI Certified
IS: 694 Standard
Uncompromising Safety & Engineering Excellence
For over two decades, Tata Gold PVC Wires & Cables has been the trusted choice for electrical contractors, architects, and homeowners across India.
99.99% Pure Electrolytic Copper
Made with 100% pure ETP grade copper strands. Lowers conductor electrical resistance, preventing heating and reducing household electricity bills.
Flame Retardant (FR) PVC Insulation
Formulated with high oxygen index PVC compound. Self-extinguishes within seconds when exposed to open flame, arresting fire spread.
100% Shock-Proof & ISI Certified
Tested to withstand over 3000 Volts spark testing. Guarantees zero leakage current and total safety against short circuit shocks.
Energy Saving & Low Voltage Drop
Optimum wire stranding ensures maximum flexibility and current flow with zero voltage drop across long distances in home wiring.
High Thermal Stability (-15°C to +70°C)
Operates smoothly in extreme summer heat and severe cold without cracking, peeling, or degrading PVC insulation strength.
Water & Chemical Resistant
Resistant to moisture, oils, grease, alkali, and chemical corrosion in wall conduits and damp masonry.
Our Premium Tata Gold Wire Range
Manufactured using 100% pure electrolytic copper and superior grade flame retardant PVC compound. Choose the perfect wire gauge for your safety needs.
Single Core FR PVC Wires
Flame Retardant Building Wires (IS 694 Certified)
High conductivity 99.99% pure electrolytic copper wire with Flame Retardant PVC compound. Prevents flame propagation during short circuits.
FRLS (Low Smoke) PVC Wires
Zero Halogen Low Smoke Insulation for Fire Safety
Specially engineered for high-rise buildings, hospitals, and luxury homes. Generates minimal non-toxic smoke and acid gas during electrical fires.
Multicore Round Flexible Cables
2 Core, 3 Core & 4 Core Flexible Copper Cables
Flexible annealed bright copper conductors insulated with tough PVC sheath. Perfect for heavy duty power tools, appliances, and panel wiring.
Submersible 3-Core Flat Cables
Heavy Duty Waterproof Cable for Agriculture & Borewells
Tough water-resistant flat PVC cables engineered to withstand deep submersion in agricultural borewells and water pumps under pressure.
Armoured & Power Distribution Cables
Heavy Duty Underground Electrical Power Supply Cables
Steel wire armoured electrical cables built for direct burial underground installations, heavy manufacturing units, and transformer feeders.
Find the Perfect Tata Gold Wire Size
Never risk short circuits or wire overheating. Calculate your electrical wattage load to get the exact safe wire gauge recommended by IS:694 standards.
Step 1: Select Application or Appliance
Pick a preset appliance to auto-fill estimated wattage:
Safe for continuous current load up to 11 Amperes
Single Core FR PVC Wire 1.0mm²
100% Pure Copper • Flame Retardant PVC
Technical Specification Matrix
Single Core PVC Insulated (Unsheathed) Cables in Voltage Grade 1100V. Manufactured as per IS: 694 standards.
TATA GOLD PVC WIRES & CABLES - SPEC CHART
100% Electrolytic Annealed Plain Copper Conductor • Voltage Grade 1100 Volts
| Nominal Area | No. / Dia. of Wire | Insulation Thickness | Current (Conduit) | Current (Unenclosed) | Max Resistance @ 20°C | Ideal Application |
|---|---|---|---|---|---|---|
| 0.75 sq.mm | 24 / 0.20 mm | 0.60 mm | 7 Amps | 8 Amps | 26.0 Ω/km | Light points, Fans & LED fittings |
| 1.00 sq.mm | 14 / 0.30 mm | 0.70 mm | 11 Amps | 12 Amps | 18.10 Ω/km | Mobile charging, TV, Computers |
| 1.50 sq.mm | 22 / 0.30 mm | 0.70 mm | 14 Amps | 15 Amps | 12.10 Ω/km | Power sockets, Refrigerator, Iron |
| 2.50 sq.mm | 36 / 0.30 mm | 0.80 mm | 19 Amps | 20 Amps | 7.41 Ω/km | 1.5 Ton AC, Microwave, Washing Machine |
| 4.00 sq.mm | 56 / 0.30 mm | 0.80 mm | 26 Amps | 27 Amps | 4.95 Ω/km | Geysers, Water Heaters, Induction Cooker |
| 6.00 sq.mm | 84 / 0.30 mm | 1.00 mm | 31 Amps | 34 Amps | 3.30 Ω/km | Main DB panel feed, Submersible Pump |
Get a Direct Factory Price Quote
Contact our sales and distribution team directly. Fill out the inquiry form and our electrical specialists will send you customized bulk pricing & delivery timelines within 2 hours.
Factory & Head Office
Tata Gold Wires & Cables Manufacturing Unit
Industrial Development Area, Sector 5, Delhi NCR, India
